Module truyền thông Mitsubishi QJ71C24N-R2 (RS-232)
-
11
-
SKU: QJ71C24N-R2
Nhà Sản Xuất: Mitsubishi
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: hóa đơn VAT
| Categories | Description |
|---|---|
| SKU | QJ71C24N-R2 |
| Interface | CH.1: RS-232 compliant (D-Sub 9P) CH.2: RS-232 compliant (D-Sub 9P) |
| Communication Method | Circuit: Full-duplex / Half-duplex Communication MELSEC Protocol: Half-duplex Communication Communication Protocol: Full-duplex / Half-duplex Communication Nonprocedural Protocol: Full-duplex / Half-duplex Communication Bidirectional Protocol: Full-duplex / Half-duplex Communication |
| Synchronization Method | Asynchronous method |
| Transmission Speed | 50 – 230,400 bps * 230,400 bps available only on CH1 * Total transmission speed of both interfaces ≤ 230,400 bps * When monitoring function is used, max total speed ≤ 115,200 bps |
| Data Format | Start Bit: 1 Data Bit: 7/8 Parity Bit: 1 (Vertical parity) / None Stop Bit: 1/2 |
| Access Cycle | MELSEC Protocol: Processed as part of END processing Communication Protocol: Executed based on dedicated command Nonprocedural Protocol: Sent per request, received anytime Bidirectional Protocol: Sent per request, received anytime |
| Error Detection | Parity Check: Applicable to all protocols, odd/even selectable Checksum Code: Selected via parameter, protocol-dependent |
| Transmission Control (RS-232) | DTR/DSR Control: Available RS/CS Control: Available CD Signal Control: Available DC1/DC3 (Xon/Xoff) Control: Available DC2/DC4 Control: Available |
| Circuit Configuration (RS-232) | MELSEC Protocol: 1:1 Communication Protocol: 1:1 Non-Procedural Protocol: 1:1 Bidirectional Protocol: 1:1 |
| Transmitting Distance | Maximum 15 m |
| Number of Occupied Inputs/Outputs | 32 points (I/O assignment: intelligent 32 points) |
| 5V DC Internal Current Consumption | 0.26 A |
| External Dimensions | Height: 98 mm Width: 27.4 mm Depth: 90 mm |
| Weight | 0.20 kg |
